Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom

Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom
Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom

Large Image :  Short Circuit Proof Optical Transport Equipment , Black Rectifier Module Telecom

Product Details:
Place of Origin: China
Brand Name: ELTEK
Certification: CE, RoHS
Model Number: Flatpack2 48/2000 HE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: carton box
Delivery Time: within 10 days of payment
Payment Terms: L/C, T/T
Supply Ability: 1000 sets/month
Detailed Product Description
Part No.: 241115.105 Efficiency: > 96% At 30~70% Load
Output Power: 2000 W At Nominal Input Maximum Current: 41.7 Amps At 48V DC And Nominal
AC Input Voltage: 85-300V AC (Nominal 185 – 275V AC) DC Output Voltage: 53.5V DC (adj. Range: 43.5-57.6V DC)
High Light:

Eltek Valere Rectifier 48V 2000W

,

Flatpack2 HE Eltek Valere Rectifier

,

241115.105​

Rectifier Modules Flatpack2 Eltek Valere 48V 2000W HE 48/2000 HE 241115.105​


Technical Specification:


AC Input:
Voltage :85-300V AC (Nominal 185 – 275V AC)
Frequency :45 to 66Hz
DC Output:
Voltage: 53.5V DC (adj. range: 43.5-57.6V DC)
Output Power : 2000 W at nominal input
Maximum Current: 41.7 Amps at 48 VDC and nominal
Output Protection: Overvoltage shutdown, Short circuit proof, High temperature protection
Efficiency:> 96% at  30~70% load
Operating Temp.:-40 to +75°C (-40 to +158°F)
MTBF :> 350, 000 hours


Mechnical Specification:


Dimensions- 109 x 41.5 x 327mm (wxhxd)
Weight- 1.95 kg (4.31lbs)


Ordering Information:


Part No.: 241115.105 Flatpack2 Rectifier Module 48/2000 HE
