Product Details:
Payment & Shipping Terms:
|
| Application: | FTTH | Certification: | ROHS |
|---|---|---|---|
| Length: | 1000 Feet | Package: | 1000 Feet/roll |
| Fiber Type: | Single Mode Or Multi Mode | Type: | FTTH 24 Core Optical Fiber Cable |
| High Light: | fiber optic ethernet cable,ftth aerial drop cable |
||
12 Core Fiber Indoor Distribution Fiber Optic Cable Singlemode 9/125 Yellow
Description
12 Fiber Indoor Distribution Fiber Optic Cable, Singlemode, 9/125, Yellow, Riser Rated, Spool, 1000 foot
Cable is composed of 2 to 24 colored tight buffers, aramid yarn, and a
PVC outer jacket. All component materials meet the EU RoHS and REACH Directive standards.
CWS Distribution Cable is available in 12 TIA standard colors or special order colors. UL Listed OFNR cables are available, and unlisted, unrated cables can be supplied to accommodate special needs. Standard surface print denotes construction, NEC rating, and fiber type, and includes footage markers. Custom print can also be accommodated.
Features
Specifications
| Item | Specifications |
| Product | Singlemode, 9/125 |
| Fiber Count | 12 |
| Outer Jacket Material | Flame Retardant PVC |
| Outer Jacket Color | Available in 12 TIA/ EIA color standard |
| Strength Member | Aramid Yarn |
| Tight Buffer Material | Flame Retardant PVC |
| Tight Buffer Color | Yellow |
| Physical Characteristics | Value |
| Nominal Outer Diameter (mm) | 6.30 |
| Weight (lbs/ km) | 94 |
|
Minimum Bend Radius, Installation (cm), of 12 (fiber count) |
9.45 |
|
Minimum Bend Radius, Operation (cm), of 12 (fiber count) |
6.30 |
| Items | Single Mode |
| Core Size | 9 um |
| Wavelength | (1310/ 1550) nm |
| Max. Attenuation | (0.5/ 0.4) dB/ Km |
