Product Details:
Payment & Shipping Terms:
|
| Color: | White | Standard: | IEEE802.3X SFP |
|---|---|---|---|
| Model Number: | 1.25G GPON SFP | Type: | Fiber Optic Transceivers |
| Fiber Type: | Single Fiber Single Mode | Application: | FTTH FTTB FTTX Network |
| High Light: | 1330nm Optical Fiber Cable Accessories,1270nm Optical Fiber Cable Accessories,IEEE802.3X SFP Optical Transceiver Module |
||
Gpon Olt Class C+/C++ Sfp 1270/1330nm Optical Transceiver Module
Specifications
| Model Number | 1.25G GPON SFP |
| Type | Fiber Optic Transceivers |
| No. of Fiber | 2. |
| Use | ftth |
| Product name | Gpon OLT Class C+/C++ sfp optical transceiver module price |
| Application | FTTH FTTB FTTX Network |
| Color | White |
| Standard | IEEE802.3X SFP |
| Wavelength | 1270/1330nm |
| Certification | CE RoHS FCC |
| OEM or ODM: Accepted | Accepted SFP OEM |
| Distance | 20KM |
| Data sheet | 10Gb/s |
| Fiber Type | Single Fiber Single Mode |
Operating Condition
| Parameter | Unit | Min. | Typical | Max. |
| Storage Temperature | °C | -40 | 85 | |
| Operating Case Temp for C-temp | °C | 0 | 70 | |
| Operating Case Temp for I-temp | °C | -40 | 85 | |
| Operating Relative Humidity | % | 5 | 95 | |
| Power Supply Voltage | V | 3.15 | 3.3 | 3.45 |
| Supply Current | mA | 600 | ||
| Bit Rate for Tx | Gbps | 2.488 | ||
| Bit Rate for Rx | Gbps | 1.244 | ||
Product Features
· Support ITU-T G.984.2 GPON OLT C+ application
· Single fiber bi-directional data links with unsymmetrical 2.488Gbps Tx and 1.244Gbps Rx
· 1490nm continuous-mode transmitter with DFB LD
· 1310nm burst-mode receiver with APD-TIA
· 2-wire interface for integrated digital diagnostic Monitoring
· Receiver RESET, Signal Detect, RSSI function indication (RESET, RX_SD, RSSI)
· SFP package with SC/UPC receptacle optical interface
· Single +3.3V power supply
· Operation case temperature -40~85°C for industrial and 0~70°C for commercial
· RoHS6 compliance
Applications:
Data services
Voice services
Video services
Monitoring service
FTTH
Maintenance service
| 1. For all the EPON and terminal units, Ethernet switch, SFP mdule and other products, New Greennet promises: Maintenance for life; 12-month maintenance for free. |
|
2. For these network products in the free maintenance regulations in the maintenance card, we provide free maintenance services within the whole country. For those not in the free maintenance regulations, we provide fee-cost maintenance service. For the products of stopping production, HUANET will preserve several products for failure exchange and maintenance. |
Technology support
| For all the EPON and terminal units, Ethernet switch, and other products, HUANET promises: |
| 1. Technology support for life: Free call and E-mail technology supports for each sold network products for life. |
| 2. Software upgrade for life: Provide upgrade software in the form of E-mail or CD for clients and clients can download it in customer service web |
