|Voltage AC:||208 - 480 VAC||Max Power:||6000 W|
|Max Voltage:||58 VDC||Cooling:||Single Fan|
|Efficiency:||96 %||Current (maximum):||125 ADC|
Eltek Rectifiers 58V 6000W,
96% Efficiency Eltek Rectifiers,
DPR6000B-48 Three Phase High Efficiency Rectifier Eltek EcoTower Scalable DC Power System
The DPR 6000B is a three-phase rectifier with outstanding efficiency and power density.
These features provide significant energy cost saving opportunities when replacing existing high power installations. The compact size allows for significant space saving in high power applications.
Advanced energy saving functionality
High power density
Low line current distortion - power factor correction
|Voltage AC (operating range)||208 - 480 VAC|
|Max Power||6000 W|
|Voltage (adjustable range)||42 - 58 VDC|
|Current (maximum)||125 ADC|
|Max voltage||58 VDC|
|Operating temperature||-40 - 65 °C|
|Storing temperature||-40 - 70 °C|
|Dimensions WxHxD (inch)||5,1 x 3,26 x 14,99 "|
|Telcordia approvals||NEBS GR1089-CORE;NEBS GR63 CORE Zone 4|
DPR6000B Rectifier Eltek EcoTower Scalable DC Power System
RICHARDSON, TX — Eltek, a Delta Group Company, has announced the new DPR6000B rectifier product line, designed for Eltek’s EcoTower and Scalable DC Power System. Both of these systems are popular in central office, cable multisystem operator (MSO), mobile telephone switching office and data center applications.
The DPR6000B rectifiers are three-phase, 125A, 48V rectifiers that can deliver up to 6kW output power. Two models are available: the DPR 6000B-48 ID:A1 for 480V input applications and the DPR6000B-48 ID:B1 for 208V input applications. The high-efficiency technology in the DPR6000B rectifiers reduces waste heat from the power conversion process, resulting in a high power-density module that delivers dramatic ongoing cost and energy savings. In fact, DPR6000B delivers 96 percent efficiency power conversion for high power applications.
The DPR6000B rectifiers are an upgrade to the legacy PowerPack rectifier family. Eltek is also offering the PowerPack 11KW Retrofit Kit that allows two DPR6000B rectifiers to occupy the same 19”-rack form factor as a PowerPack rectifier.
“The applications served by this new rectifier family need growing amounts of power and will reap a significant operating expense benefit from upgrading to HE technology,” said Roel Cortez, Vice President of Sales & Marketing at Eltek. “The addition of the DPR6000B family will mean customers can continue to count on the Scalable System and EcoTower to deliver reliable and efficient power conversion and distribution.”
The Eltek EcoTower DC Power System measures 24” W x 84” H x 24.8” and is a single-cabinet solution for medium and large power applications. The EcoTower has a front-access design and has a maximum output of 2400A. The system can be equipped with as many as four different DC distribution panels per cabinet and can support up to eight battery connections. In addition to DPR6000B rectifiers, the EcoTower also supports Flatpack2 HE 48V rectifiers for up to 2400A of output power. The system is managed by the Smartpack2 controller.
The Eltek Scalable DC power system is composed of rectifier bays and optional distribution bays. A rectifier bay can hold up to 30 DPR6000B rectifiers for a total output of up to 3,000A. Up to four rectifier bay cabinets can be cabled together to support very high-power applications. At scale out, the system can support up to 500,000 watts.
Distribution bays support flexible distribution options including bulk buses (3000A, 6000A and 10000A rated) or up to 48 configurable distribution positions. Rectifier and distribution bays can be connected through an Eltek designed internal bus that acts like a system bus, or a traditional overhead bus structure. An entire system, including battery and/or gen-set back up, is controlled by Eltek’s Smartpack2 controller.
About Eltek: Eltek is a strategic technology partner for power solutions. The company has operations in more than 40 countries. Eltek focuses on power electronics markets, where it is one of the leaders in telecom power and a growing force within industrial applications. Eltek is also pursuing growth opportunities within the datacenter market. Eltek is headquartered in Drammen, Norway and became part of Delta Group in 2015, a leading power and thermal management provider.
